HD40

Golden Line

Released in 2019, the HD40 represents a new design philosophy for Trillium. A unique bearing arrangement and Magnesium monocoque structure was paired with the latest optical zoom cameras to deliver unparalleled performance in a 4” diameter gimbal.

HD40 Rectangle

Features:

Golden Line

Machined Magnesium Housing – robust and environmentally sealed
Onboard GPS/INS – accurate gimbal and target location
MISB Compliant Video – h.264 video and KLV metadata
Onboard Video Processing – electronic image stabilization and scene tracking
Video and Control Over Ethernet – single 10/100 connection
Direct Drive Motors – best in class stability
Non-ITAR – simple export options
ITAR Required

Configurations

Golden Line

HD40-XV
The HD40-XV is an EO only configuration with a 33x optical zoom visible camera.
Weight: 850g

HD40-LV
The HD40-LV is an EO/IR configuration with a 10x optical zoom visible camera and a fixed focal length uncooled LWIR camera.
Weight: 600g

Downloads

Golden Line

Accessories

Golden Line
HD25 Rectangle 18

EXTERNAL REGULATOR

The HD40 requires regulated 24V for operation. We offer two variations of power regulation optimized for 10V to 21V in, or 17V to 34V in, both providing 24V out.

HD25

DEVELOPMENT KIT

The development kit contains everything you need to work with the gimbal on a bench including, an interface cable, a desktop power supply, and a GPS antenna. A development kit is recommended for all new purchases.
